NPT is the abbreviation used for National Pipe Thread Taper.
Table below shows the relation between Nominal pipe size, Nominal diameter & outside diameter for pipes: Nominal Pipe size Pipe sizes are documented by a number of standards, including API 5L, ANSI/ASME B36.10M in the US, BS 1600 and BS EN 10255 in the United Kingdom and Europe, and ISO 65 internationally.įor NPS of 5 and larger, the DN is equal to the NPS multiplied by 25 (not 25.4). For a given SCH, the OD increases with increasing NPS while the wall thickness increases or stays constant. For a given NPS, the OD stays constant and the wall thickness increases with larger SCH. For NPS 14 and larger, the NPS is equal to the outside diameter (OD) in inches. The NPS is very loosely related to the inside diameter in inches, but only for NPS 1/8 to NPS 12. OD is the outside diameter of the pipe and is fixed for a given size. NB ( nominal bore) is also frequently used interchangeably with NPS.
NB ( nominal bore) is the European designation equivalent to NPS is DN (diamètre nominal/nominal diameter/Durchmesser nach Norm), in which sizes are measured in millimeters. NPS is often incorrectly called National Pipe Size, due to confusion with national pipe thread (NPT) Pipe size is specified with two non-dimensional numbers: a nominal pipe size (NPS) for diameter based on inches, and a schedule (Sched. Nominal Pipe Size ( NPS) is a North American set of standard sizes for pipes used for high or low pressures and temperatures.
What is NPT & what are its applications? What is a relation between NPS, NB & OD of a pipe? What is a relation between NPS, NB & OD of a pipe?
